VersaUV LEF2-200 Benchtop Flatbed UV Printer

Roland DG

from $ 32,994.50 GST Incl.



The Creative Possibilities of ECO UV Ink



With optimised ease and efficiency, you can print directly onto accessories, giftware, ceramics, and countless other popular products. Create unique, desirable and highly-profitable custom items with the VersaUV LEF2-200 flatbed UV printer that offers brilliant colour results, realistic textures and stylish embossed effects.



Feel the Colour with Gloss ECO-UV Ink



Gloss Finish



Print gloss/matte finishes, realistic textures, or 3D embossed effects to add an irresistible new dimension of “touch and colour”. Create your own special finishes or choose from seventy-two ready-to-use texture patterns in our Roland DG Texture System Library.

leaves texture printed lef2-200leather texture printed on LEF2-200metal texture printed on LEF2-200Wood texture printed on an LEF2-200Lace texture printed on an LEF2-200Stitching texture printed on an LEF2-200



Advanced Ink Printing



Print graphics with consistent colour and incredible detail on a virtually unlimited range of promotional products.

  • Produce stunning graphics with CMYK, White and Gloss ECO-UV (EUV4) inks
  • White ink acts as a brilliant spot colour, or to ensure that colours pop on dark or clear substrates
  • Optional Primer increases efficiency by prepping the surface of materials like acrylic and plastic for full-colour customisation*
  • An Automated Ink Circulation System prevents ink pigments settling in the ink lines for smooth consistency and density
  • Mist Filters catch the residual ink that mists off the edge of your media to prevent overspray and to keep ink from settling on internal components
  • For best primer results, it is strongly recommended that users test for adhesion to specific substrates prior to final production.





A Convenient, Clean, and Supercool Machine Experience



With state-of-the-art, low-heat UV-LED lamps, and self-wicking ink features, the fully-enclosed LEF2-200 flatbed UV printer is simple-to-operate and runs clean and cool with a safeguarded operation. In addition to eliminating additional machine movements of previous models to give you a more efficient operation, it offers new machine advantages to streamline your print process.



Reliability, Warranty and Support

Built to provide years of reliable service – even in the most demanding print environments – Roland DG’s wide format printers come with a 1, 3 or 5 Year Warranty.

Roland DG has earned a reputation for long-lasting, high-performance devices, backed by first-rate customer service. This support includes expert technical assistance, videos and free Roland software updates for the lifetime of the machine.

Roland DG's international ISO certifications are your assurance of quality products and service.warranty





Download Brochure

Specifications:

Model LEF2-200
Printing method Piezo ink-jet method
Attachable objects to be printed on - Width Max. 538 mm
Attachable objects to be printed on - Length Max. 360 mm
Attachable objects to be printed on - Thickness Max. 100 mm
Attachable objects to be printed on - Weight Max. 5kg
Maximum printing width / printing length Max. 508 (width) × 330 (length) mm
Ink - Type ECO-UV (EUV, EUV4) 220 ml cartridge
Ink - Colors Five colours (cyan, magenta, yellow, black, and white)
Five colours (cyan, magenta, yellow, black, and white) and primer
Six colours (cyan, magenta, yellow, black, white, and gloss)
Ink-curing unit Built-in UV-LED lamp
Print resolution (dots per inch) Max. 1440 dpi
Distance accuracy* Error of less than +/-0.3% of distance traveled or +/-0.3 mm (+/-11.8 mil), whichever is greater.
Connectivity Ethernet (10BASE-T/100BASE-TX, automatic switching)
Power-saving function Automatic sleep feature
Power requirements AC 100 to 240 V ± 10%, 1.8 A, 50/60 Hz
Power consumption - During operation Approx. 149 W
Power consumption - Sleep mode Approx. 13 W
Acoustic noise level - During operation 60 dB (A) or less
Acoustic noise level - During standby 49 dB (A) or less
Outer dimensions 1,202 (W) × 962 (D) × 549 (H) mm
Weight 110 kg
Environment - During operation Temperature: 20 to 32°C (22°C or higher recommended)
Humidity: 35 to 80% RH (no condensation)
Environment - Not operating Temperature: 5 to 40°C
Humidity: 20 to 80% RH (no condensation)
Included items Power cord, software RIP, cleaning liquid, drain bottle, manuals, etc.













  • Roland ECO-UV Inks (Version 4)

    Printing
    Multiple Options
  LEF-12i LEF2-200 LEF2-300
Max. Print Area 305 x 280 mm 508 x 330 mm 770 x 330 mm
Max. Media (Width x Depth x Thickness) 335 x 310 x 100 mm 538 x 360 x 100 mm 800 x 360 x 100 mm
Max Media Weight 5 kg 5 kg 8 kg
Printing Uni-Directional Uni-Directional Bi-Directional
Ink Configuration Options CMYK + Clear (gloss) + White
  • CMYK + Clear (gloss) + White
  • CMYK + Primer + White
  • CMYK + White + White
  • CMYK + Clear (gloss) + Clear (gloss)+ White
  • CMYK + Clear (gloss) + White+ Primer

Promotional Items



With its ability to print CMYK, White and Clear inks directly around the curves and contours of three-dimensional objects, the LEF2-200 is ideally suited for personalising pens, golf balls, key chains and other promotional items. Variable data printing allows you to individualise each item with names, photos and other custom design elements.

usb
electrical product

Electronic Devices



Low-heat LED curing systems make the LEF2-200 ideal for printing on sensitive electronic devices, including tablets and smartphones. High-opacity White ink produces bright, crisp white text and graphics, and can also be printed as an undercoat to enhance full-colour graphics on clear acrylics and darker plastics.

Giftware



With the LEF2-200, you can print directly on gift items ranging from jewelry and accessories to photo frames, wedding favors, dishware and even fabric items such as leather wallets and purses. Add interesting patterns and textures to your designs with layers of Gloss ink in matte or gloss.



Wine Case

bottle design

*requires rotary accessory

Awards



The LEF2-200 is the perfect addition to awards and recognition businesses, allowing these shops to add full-colour graphics to engraved items for high-impact results. White ink allows you to print on clear acrylic awards as well as dark-colored plaques. Gloss ink adds elegant embossing and varnishing effects for a premium presentation.

Consumer and Industrial Products



For product designers, entrepreneurs and marketing professionals, the LEF2-200 customises a wide variety of products from toys and sports items to cosmetic cases and control panels. Variable data printing allows you to mark each product or part with individual serial and lot numbers.

product application
Glass and ceramics

Small signage



With the LEF2-200, you can create a wide range of specialised signs for objects such as car doors, windows and interior spaces. Print directly on wood and other specialty materials for a truly unique look.



Features
