from $ 27,494.50 GST Incl.
The Texart RT-640 is a state-of-the-art device that fits effortlessly into sublimation printing workflows for productions ranging from fabric banners and branded apparel to promotional items and interior décor. Roland DG’s Texart solution includes the Texart printer, Texart inks, ErgoSoft Roland edition RIP software and options for accessories like transfer paper, making it easy for you to get into – or increase – your sublimation business.
The RT-640 is designed for maximum ease-of-use. An automatic feed adjuster and media take-up system ensure even tensioning and prevent skewing of transfer paper, while a powerful vacuum keeps paper flat for printing. The result is precision details and a precisely wound roll at the take-up reel, ready for heat transferring. An innovative Roland Ink Switching System automatically switches to the backup ink pouch when the primary pouch runs out, providing up to 2000ml of ink per colour in CMYK mode. Included ErgoSoft sublimation RIP software and Roland Printer Assist iPad app make it easy to manage operation.
The RT-640 includes a feed adjustment function that combines with a TU3 take-up attachment to ensure a stable and uninterrupted production even in high-speed modes. The TU3 take-up system includes a front-mounted roller and tension controlled take-up unit for smooth media feeding and tracking. Its main features include a roll media support that holds 50kg, a dancer roller for effortless take-up, auto media release and auto media rewind, and a rotating shaft face to decrease resistance and ensure flawless feeding accuracy.
Achieve vivid colours, smooth gradations and super-sharp images with fast-drying Texart dye sublimation inks. Specially formulated for Texart dye sublimation printers, Texart ink delivers dense blacks, a wide colour gamut that includes Orange and Violet ink options, and a high dye concentration that reduces ink-limits without any reduction in colour density or vibrancy. Texart SBL3 ink is also available in Fluorescent Pink and Yellow inks that produce hundreds of vivid fluorescent colours and soft pastel shades for fashionable sportswear, decor and eye-catching signs.
The Texart RT-640 can be configured as a 4-colour or 8-colour device. In 4-colour (CMYK) mode, Texart ink produces bright colours with velvety blacks, improved grey scale and high quality, detailed output. In 8-colour (CMYK+LcLmOrVi and CMYK+OrViFpFy) mode, the addition of Orange, Violet, Fluorescent Pink and Fluorescent Yellow inks produce an increased colour gamut with both delicate and intense hues. Fluorescent Pink and Yellow inks can be combined with process colors (CMY+Fp+Fy) to produce an array of vivid fluorescents and soft pastel shades.
An advanced, 8-channel print head contains 180 nozzles per channel capable of producing seven different droplet sizes for smoother gradations and denser colour. Texart ink is approximately 15% less expensive per litre than conventional inks, yet provides outstanding colour reproduction. Lower running costs are also achieved due to the ink waveform and maintenance sequence control technology engineered for Texart ink and the RT-640.
The Roland Ink System uses airtight sealed pouches of one litre each. When in 4-colour mode, the system provides two litres per colour. The proprietary Roland Ink Switching System* automatically switches to the backup ink pouch when the primary pouch runs out. Further expediting production, you can replace an empty pouch without stopping the printer.* Available only in 4-colour mode
The RT-640 printer is backed by a comprehensive 3-Year Heads ‘n All Warranty. Roland DG is committed to customer satisfaction and providing unmatched reliability, earning a reputation for long-lasting, high-performance devices backed by first-rate customer service. Roland DG proudly displays all international ISO certifications as your assurance of superior quality.
|Media - Width||259 to 1,625 mm|
|Media - Thickness||Maximum 1.0 mm|
|Media - Roll outer diameter||Maximum 210 mm|
|Media - Roll weight||Maximum 40 kg|
|Media - Core diameter (1)||76.2 mm or 50.8 mm|
|Printing width (2)||Maximum 1,615 mm|
|Ink pouches - Types||Exclusive sublimation ink pouch|
|Ink pouches - Colours||4-colour (CMYK) and 8-colour (Choose from CMYK+LcLmOrVi and CMYK+OrViFpFy options)
Available colours: cyan, magenta, yellow, black, light cyan, light magenta, orange, violet, fluorescent pink, and fluorescent yellow
|Printing resolution (dots per inch)||Maximum 1,440 dpi|
|Distance accuracy (3)||Error of less than ±0.3% of distance traveled, or ±0.3 mm, whichever is greater|
|Connectivity||Ethernet (10BASE-T/100BASE-TX, automatic switching)|
|Power-saving function||Automatic sleep feature|
|Power requirements||AC 100 to 240 V ±10%, 1.5 A, 50/60 Hz|
|Power consumption - During operation||Approx. 140 W|
|Power consumption - Sleep mode||Approx. 31 W|
|Acoustic noise level - During operation||62 dB (A) or less|
|Acoustic noise level - During standby||49 dB (A) or less|
|Dimensions (with stand)||2,650 mm (W) x 795 mm (D) x 1,600 mm|
|Weight (with stand)||160 kg|
|Environment -||Temperature: 18 to 25° C, humidity: 35 to 65% RH (non-condensing)|
|Environment -||Temperature: 15 to 30° C, humidity: 20 to 80% RH (non-condensing)|
|Accessories||Exclusive stands, power cord, media clamps, media holder, replace- ment blades for separating knife, User's Manual, etc.|
(1) The media holder of this machine is exclusive use for the media of paper tube (core) inner diameter 3 inches. To use 2 inches media, the optional media flanges are required.
(2)The length of printing is subject to the limitations of the program.
(3) Media type: Media specified by Roland DG Corp.• Temperature: 25°C (77°F), humidity: 50%• Roll media must be loaded correctly.• Excluding expansion/contraction of the media• All corrections or adjustment function of this machine have been made properly.• Print travel: 1 m
Thanks to Roland Printer Assist, you can manage your RT-640 remotely when you're in the office using an iPad tablet. Free and available for download from the iTunes App Store, the Roland Printer Assist app enables users to manage production, test printing, and even access cleaning functions from virtually any location. You can instantly observe key operating functions such as the amount of ink remaining and waste bottle status. Roland Printer Assist notifies you when consumable parts replacement should be performed to ensure printer reliability. Roland Printer Assist allows you to manage multiple printers from a single iPad.
ErgoSoft Roland Edition was developed especially for Roland by ErgoSoft, the premier RIP provider in the textile market. Support for both 4-colour and 8-colour printing is provided and it includes numerous features especially for digital textile production that combine excellent high-speed RIP throughput and image quality.
Dye-sublimation is a beautifully simple and affordable method of customisation. With a large format set-up that includes an RT-640 and a price comparable heat press, you can get the most bang-for-your-buck as far as graphics and product branding goes. Simply print your design onto transfer paper and heat press it onto the available product blanks and dye-sublimation substrates:
Polyester fabrics - Chroma - Luxe metal panels - Ceramic items - Thongs
Lycra and performance Fabrics - Sporting goods - Smart Device Cases - Carpet tiles
